New range of Inazuma Nataris drum, low voltage filter for swimming
Completely equipped with LOW VOLTAGE 12 V specially designed for swimming!
The Inazuma Nataris 100 drum filter filters your swimming pool/swimming pool thoroughly, reliably and fully automatically, without any consumables, thus saving energy and conserving resources.
It is suitable for use in pools of up to 200 m³.
It is completely equipped with 12 V LOW VOLTAGE specially designed for swimming!
Thanks to a clever design, the filter can be used for both pumped operation and gravity installation.
Industrial grade, food grade V2A stainless steel is used as the material for the filter housing and drum. Dry-running protection, safety overflow and other innovations such as the Speedflush® gutter flushing system and the Cleanbrush® scraper brush are standard equipment.
The low maintenance costs of an Inazuma filter are particularly satisfactory. It only requires purified pond water for the rinsing process and no consumables such as fleece. Instead, impurities are reliably removed from the system thanks to the robust coating of the drum with 50 μ V2A stainless steel mesh.
Installing, connecting and starting your filter is incredibly simple.
The filter is delivered to you fully assembled and ready to install.
Install the filter, connect it to the plumbing, plug in the power plug and you are on your way to purifying water and enjoying pure bathing pleasure.
With the Internet-enabled Nataris Control (app available for Android and IOS), you can easily view and control many parameters from anywhere in the world using your mobile phone or tablet.
The system can be individually adapted to your needs using a temperature sensor and level control.
The Nataris command can also be used with the app without an internet connection.
- Nataris drum filter
- Nataris control including sensors and external WLAN outdoor antenna
- External power supply with weather protection box including a 10 meter connection cable (maximum distance power supply <> filter)
The 10-year guaranteed supply of spare parts directly from the manufacturer guarantees many years of enjoyment with a robust, low-maintenance filter made in Germany.
Mode de filtration | Pompage / gravitaire | |
Volume baignade - piscine maxi | m3 | 200 |
Matériau | Acier Inox V2A | |
Poids | kg | 115 |
Dimensions L x l x H | mm | Info va suivre |
Surface du tamis immergé | mm2 | 707300 |
Finesse de filtration | micron | 50 |
Entrée | mm | 5 x 110 |
Sortie | mm | 5 x 110 |
Sortie eaux usées | mm | 1 x 110 |
Débit max pompage (10 mg MES / litre) | m3 / heure | 45 |
Débit max gravitaire (10 mg MES / litre) | m3 / heure | 60 |
Technologie basse tension moteur pompe | V | 12 V |
technologie basse tension commande | V | 12 V |
Inclus | Contrôle WiFi | |
Inclus | Prêt pour montage solaire | |
Inclus | Protection anti-débordement | |
Inclus | Protection marche à sec |
Temperature sensor
Automatic water level compensator
